Código de producto : VF--DCC-D95-CU
Size :20"-36"(DN500 - DN900)
Valve material: cast iron, ductile iron, stainless steel 316
Port type: Flange
Valve seat material: Nitrile rubber (NBR), ethylene propylene diene monomer (EPDM), chloroprene rubber (NEOPRENE), silicone rubber (SILICON), chlorosulfonated polyethylene rubber (HYPALON), fluorinated rubber (VITON)
Valve disc material: ductile iron, stainless steel 316, bronze
Valve stem material: Stainless steel 316
Contáctenos si necesita servicios personalizados. Le informaremos el precio y la disponibilidad en 24 horas.
| Producto | Código de producto | Pureza | Tamaño | Contáctenos |
Structural length: ISO5752
2. Installation platform with ISO5211 flange
3. Flange requirements: American standard ANSI150, Japanese standard JIS10K, German standard DINPN10,DINPN16
4. Quality Assurance: ISO9001,PED97/23/EC
5. Quota :20" to 36":150PSI(10BAR)
6. Selection: Gear. Pneumatic or electric operation
7. Application scope: water, sewage treatment, air, oil, energy, natural gas, etc
Application scope: water, sewage treatment, air, oil, energy, natural gas, etc
Packing of Standard Packing:
Typical bulk packaging includes palletized plastic 5 gallon/25 kg. pails, fiber and steel drums to 1 ton super sacks in full container (FCL) or truck load (T/L) quantities. Research and sample quantities and hygroscopic, oxidizing or other air sensitive materials may be packaged under argon or vacuum. Solutions are packaged in polypropylene, plastic or glass jars up to palletized 470 gallon liquid totes Special package is available on request. E FORUs’ is carefully handled to minimize damage during storage and transportation and to preserve the quality of our products in their original condition.
